270 Ton Horizontal Automatic Plastic Injection Machine Clear PET Juice Water Preform

Name: 270 Ton Horizontal Automatic Plastic Injection Machine Clear PET Juice Water Preform
Brand: DAWSON
Price: 27 USD

Buy cheap 270 Ton Horizontal Automatic Plastic Injection Machine Clear PET Juice Water Preform product

Injection weight : 1006g (PET)

Platen stroke : 540mm

Plasticizing capacity : 295 g/s

Warranty : 1 year

Preform neck : 20~120mm

Brand Name : DAWSON

Model Number : PET270S/1000

Certification : CE

Place of Origin : CHINA

MOQ : 1 set

Price : USD 27,500 ~ 29,000 / set

Payment Terms : L/C,T/T

Supply Ability : 200 sets / month

Delivery Time : 5-8 weeks

Packaging Details : Standard Export Packing

Style : Horizontal

Language : English, Chinese or other specified

Screw diameter : 62mm

Output : 3000~3500 pcs/h

Space between tie bar : 570*570mm

Mould thickness : 200~550mm

Clamping force : 2700 KN

Contact Now

270 Ton Horizontal Automatic Plastic Injection Machine Clear PET Juice Water Preform

DAWSON MACHINERY & MOULD GROUP

Injection Molding Machine

Specialized for making PET preforms, special screw for PET products, all machine adapt latest Taiwan control system,
Japan YUKEN hydraulic valve for highest quality standard and machine performance.
We also able to provide mould designing and manufacturing to help you build up all kinds of plastic items manufacturing.
Injection molding machine is suitable for multiple types of products as well, such as caps , pails, buckets, jars, covers, lids, basins...

270 Ton Horizontal Automatic Plastic Injection Machine Clear PET Juice Water Preform

Technical Parameters

Parameters		PET170S/530	PET230S/1000	PET270S/1000	PET270S/1500
Screw diameter	mm	50	62	62	70
Theoretical shot volume	cm3	450	860	860	1300
Shot weight	g	527	1006	1006	1521
Clamping force	KN	1700	2300	2700	2700
Toggle stroke	mm	435	475	540	540
Ejector stroke	mm	135	140	150	150
Space between tie bars	mm	460 * 460	520 * 520	570 * 570	570 * 570
Mould thickness	mm	180 ~ 500	200 ~ 530	200 ~ 550	200 ~ 550
Motor power	kw	28	36	43	56
Machine size	m	5.5 * 1.4 * 2.1	6.14 * 1.5 * 2.14	6.34 * 1.6 * 2.25	7.21 * 1.7 * 2.37

Details Images

DAWSON MACHINERY & MOULD GROUP

Our customers from all over the world

Including Asia, Africa, South America, Europe countries, such as Thailand, Indonesia, India, Philippines, Ecuador, Colombia, Guatemala, South Africa, Malawi...

Local service team in

Saudi Arabia, Colombia, Panama, South Africa ... etc

DAWSON MACHINE & MOULD GROUP is devoted to the plastic machinery industry since 2003.

We are located in Zhangjiagang city, which is 2 hours' driving from Shanghai. Very convenient for you to visit us from there. We developed professional engineering, production, aftersale group during the past years. Welcome to send inquiry or come to our factory.

Reliable friend Dawson, always the max supprt!
